BALIZA LED 191XL 120/240VAC NEMA 4X IP66 3/4″ NPT UL LISTED ROJO 191XL-S120240R FEDERAL SIGNAL
Flashing LED Hazardous Location Warning Light with XLT™ Model 191XL The model 191XL is a hazardous location flashing signal light that features the super bright LED array with XLTTM , eXtreme Light Technology. The unit is available in 24VAC/DC, 120VAC or 240VAC and five colors: Amber, Blue, Clear, Green, and Red. The 191XL comes standard in flashing mode and is field configurable to steady burn mode for maximum functionality. The Model 191XL has been certified by UL as meeting Type 4X water-tight and corrosion-resistant requirements, and IP66 rated. This hazardous location warning light has an aluminum base, coated for corrosion-resistance, that can be ordered. A dome guard fits over the glass dome to protect it against accidental collision with moving equipment, such as a forklift. Federal Signal’s super bright LED array used in the 191XL produces intense light output and 60,000 hours of service. Increased shock and vibration resistance add to this unit’s rugged industrial portfolio of features. The 191XL is UL Listed for Class I, Division 2, Groups A, B, C and D; Class II Division 1, Groups E, F and G; and Class III.
RUGGED DESIGN FOR USE IN HAZARDOUS LOCATIONS • XLTTM Technology • Available in 24VAC/DC, 120-240VAC and 277VAC • Five lamp/lens colors • Flashing mode standard, configurable to Steady-burn • 60,000 hour, vibration resistant LED lamp • Available in 3 /4-inch NPT pipe mount or surface mount • Dome guard included • Type 4X, IP66 enclosure, Marine Listed • UL and cUL Listed
Operating In-rush Flash Model Voltage Current Current Rate/Minute Mount 191XL-*024** 24VAC/DC 0.40 amps 1.75 amps, 5.0 mS 60 3 /4″ NPT Pipe 191XL-*120-240_** 120/240VAC 0.21/0.13 amps 2.0 amps, 0.25 mS 60 3 /4″ NPT Pipe 191XL-*277_** 277VAC 0.13 amps 9.75 amps, 0.25mS 60 3 /4″ NPT Pipe Hazardous Location 24V 100-265VAC 277VAC 24V 100-265VAC 277VAC 24V 100-265VAC 277VAC Class I, Div 2, Groups A, B, C, D T6 T6 T5 T5 T5 T5 T4A T4A T5 Class II, Div 1, Groups E, F and G T6 T6 T5 T6 T6 T5 T6 T6 T5 Class III T6 T6 T5 T6 T6 T5 T6 T6 T5
