CIRCULINA 240VAC NEMA 4X AZUL LP3T-240B FEDERAL SIGNAL
Model LP3 is offered in five mounting configurations. The LP3S features a three-hole surface mount — ideal for control panels and other flat or flush surfaces. The LP3E features a standard A-19 medium Edison screw-in base. The LP3M features a 1/2″ NPT male pipe mount and 18″ wire leads. LP3P features an integrated 1/2-inch NPT pipe mount. The “T-mount” LP3T has a popular 2-hole design for wall or flush mounting. Models LP3M, LP3S and LP3T include a surface gasket to complete the Type 4X installation. An optional dome guard is available for use with the LP3M, LP3S and LP3T when installed flush with a panel. All LP3 units feature a threaded screwon lens to allow for tool free wiring and strobe tube replacement. StreamLine® strobes feature high-quality, long-life strobe tubes which are designed to reduce tungsten build-up for longer lamp maintenance cycles. Careful consideration is given to the relationship between tube shape and lens design for maximum light output. The high-quality dry-electrolyte capacitor used in StreamLine products runs cooler than those used in many competitive strobes, resulting in a more reliable product that won’t fail due to overheating.
FEATURES
• Available in 12-48VDC, 120VAC and 240VAC; LP3E only available in 120VAC • Edison mount (E), 1/2″ NPT male pipe mount (M), Surface mount (S), T-mount (T), integrated 1/2-inch NPT pipe mount (P) • Five dome colors: Amber, Blue, Clear, Green and Red • Screw-on lens provides easy access • Low profile — Model LP3S is only 5″ high • Models LP3M, LP3P and LP3S are Type 4X, IP66, IP69K enclosure Models LP3E and LP3T are Type 4X, IP66 only • PLC and triac compatible • UL and cUL Listed and CSA Certified Models LP3E, LP3M, LP3P, LP3S, LP3T StreamLine® Low Profile Strobe Light MODEL VOLTAGE OPERATING CURRENT FLASH RATE/ MINUTE LIGHT OUTPUT PEAK 1 ECP 2 LP3*-012-048** 12-48VDC 0.44-0.10 amps 80 (+/-15) 175,000 cd 51.5 cd LP3*-120** 120VAC 0.10 amps 80 (+/-15) 175,000 cd 51.5 cd LP3*-240** 240VAC 0.07 amps 80 (+/-15) 175,000 cd 51.5 cd * Indicates Mounting Style: (E) Edison A-19 Screw-in Base, (M) Male Pipe Mount, (P) Pipe Mount, (S) Surface Mount, (T) T-Mount ** Indicates color: (A) Amber, (B) Blue, (C) Clear, (G) Green or (R) Red 1 Peak candela is the maximum light intensity generated by a flashing light during its light pulse 2 ECP (Effective Candela) is the intensity that would appear to an observer if the light were burning steadily
