S125LR
CIRCULINA GIRATORIA SERIES S125LR LED QLIGHT
Ø125mm LED Revolving Warning Light
CIRCULINA GIRATORIA SERIES LED QLIGHT
Circulina LED Giratoria Serie: S125LR de 120-140RPM, con LED de alta eficiencia y larga vida util, patentado por QLIGHT, Grado de Protección: IP44, para servicio continuo.
• Ø125mm standard LED revolving warning lights • Excellent omni-directional visibility with LED light collecting system and special multifaceted reflector • Built-in buzzer available(Volume : Max 90dB at 1m) • Revolving speed : 120-140RPM • Materials : Lens – AS, Housing – ABS, Reflector – Heat resistant ABS • Ambient operating temperature : -20°C to +50°C
• External power line standard : UL1015 AWG18(0.75sq)×2C 400mm • DC Type: Black output line is negative(-) • Ø125mm standard LED revolving warning lights • Excellent omni-directional visibility with LED light collecting system and special multifaceted reflector • Built-in buzzer available(Volume : Max 90dB at 1m) • Revolving speed : 120-140RPM • Materials : Lens – AS, Housing – ABS, Reflector – Heat resistant ABS • Ambient operating temperature : -20°C to +50°C Model number Voltage Current Certificates Weight Color DC12V 0.422A – 0.43kg ● R-Red ● A-Amber ● G-Green ● B-Blue DC24V 0.266A 0.43kg AC110V 0.082A 0.66kg AC220V 0.041A 0.66kg Ordering Specification Wiring Instructions Technical Diagram S125LR LED Revolving Warning Light Common Specifications(MLR) Customization 44 5020 90 • 2 buzzer sound types : Both prolonged(beep, beep) and staccato(beep, beep, beep) buzzer output available (Units : mm) • Same design with S1Model number : S1all mount bracket options : Bracket structure allows for threading through the bracket hole or into the wall mount Feature of LED revolving warning light LED revolving warning light has Qlight’s distinctive LED light collecting system and special multifaceted reflector allowing excellent omni-directional visibility. (Patent registered) S – BZ – 220 – R [Model number] [Buzzer option] [Voltage] [Color] | | | | • SNone – No buzzer • BZ – Built-in buzzer • 12-DC12V • 24-DC24V • 110-AC110V • 220-AC220V ● R-Red ● A-Amber ● G-Green ● B-Blue
