QMHL-250-MF
http://mcsuministros.com/wp-content/uploads/2024/04/QML-QMHL-QLIGHT.pdf
REFLECTOR LED WORK HEAVY DUTY 25W 24VDC 1900LUX IP67/ IP69K UL LISTED QMHL-250-MF QLIGHT
Water, vibration and oil resistant LED work light, suitable for machine tools applications and high temperature water cleaning environments QMHL-250-MF
• Excellent oil resistance with a special sealing structure with IP67 protection rating, suitable for machine tool applications with cutting fluids • Suitable for high pressure and high temperature water cleaning environments(IP69K) • Tempered glass prevents damage from machine tool chips • Foreign substances do not accumulate on the shielding glass surface of the working light due to its flush structure to the housing structure of the product • Can select between QML model (Anti-glare type) and QMHL model (High luminance type) depending on your work conditions • An external power supply is not needed for the AC type product; AC voltage can be applied directly to the product • Can select from a variety of bracket options from direct mount, tilt mount, and pan/ tilt mount type to fit your work environment or lighting condition needs • Can customize the product with the M12 connector if requested • Customized oil resistant cable attached type available • Certificates : CE Compliant, UL Listed • Water and oil resistant MF type brackets protect output cable from cutting fluid and chips • Has a tilt adjustment angle of 180° and a pan angle of 160° Common Specifications(QML/ QMHL) Vibration Resistance Test • Acceleration : 20m/s2 • Duration : 1 octave/min • Range of frequency : 10-150Hz • Amplitude : 10 times maximum 7.5mm, direction : test 10times in 3 directions(X, Y, Z) Shock Resistance Test • Acceleration : 20g • Directions : ±X, ±Y, ±Z • Numbers : 3 times each directions • Time period : 11ms for each direction • Waveform : Half sine Oil Resistance Test • General test : Tested in water soluble and non-water soluble flooded environments for 500 hours. • High temperature oil resistance test : Place the object in a constant temperature water bath at 80°C for two hours and then submerge the object in the room temperature oil diluent for 24hours. Solid Particle Protection Test(IP6X) • After reducing the pressure inside the test object, spray talcum powder with a nominal diameter of 50um for 2 hours at 40-60meters/hour inside the dust chamber. • IEC60529 Liquid Ingress Protection Test(IPX7) • Test ingress by putting the object under 1000mm water with 2bar of pressure for 30 mins High-pressure, High-temperature Wash-down Test (IP69K) • Spray nozzle provides 80°C water with pressure of 80–100 bar and a flow rate of 14–16 L/min to the object • Distance between spray nozzle and the test object : 10-15cm • Water spray angle : 0˚, 30˚, 60˚, 90˚ • The nozzle is held at 4 of each angle for 30 seconds • DIN 40050 PART9 SIDE VIEW 90˚ 90˚ SIDE VIEW 90˚ 90˚ TOP VIEW 80˚ 80˚ Has tilt adjustment with wide angle of 180° Customized cable entry M12 connector attached type available Water, vibration and oil resistant LED work light, suitable for machine tools applications and high temperature water cleaning environments 67 69K 30 60 QML/ QMHL Water, Vibration and Oil Resistant LED Work Lights with IP67/ IP69K Protection Tilt Type K Bracket Cable entry M12 connector attached type Tilt/ Pan Type MF Bracket, Water and Oil Resistant QMHL-250-MF
