350WBX
Bocina Vibratone Serie ecibeles: 110 Marca: Federal Signal
Model X (AC current) Vibratone® horn produces sound by the electro-mechanical vibration of a stainless steel diaphragm. The horn mechanism with diaphragm is attached to the grille. The water- and dust-tight backbox is ideal for indoor or outdoor use. The ModelX is available in 120 or 240VAC for 50/60Hz. Its sound output level is 100dBA nominal at ten feet (110dBA @ 1 meter). This hazardous location horn accommodates surface, flush or semi-flush mounting on walls, panels, and in cabinets. The Model 350WBX features a die-cast zinc housing with a corrosion-resistant polyurethane finish. The rugged outer grille resists vandalism without reducing sound output. The 3used and utilizes a terminal block connection. TheWX is approved for Class I, Division 2, Groups A, B, C and D; Class II, Division 2, Groups F and G; and Class III. Capable of producing coded blasts or sustained tones, Federal Signal’s Vibratone horns are excellent for general alarm, start/ dismissal, coded paging and process control signaling in areas where their sound output exceeds ambient noise levels. Compact size and a variety of installation options make them ideal for institutional use.
SPECIFICATIONS
Operating Temperature: -65°F to 150°F -54°C to
66°C
Net Weight: 2.7 lbs. 1.2 kg
Shipping Weight: 2.8 lbs. 1.2 kg
Height: 4.53″ 115.0 mm
Width: 4.53″ 115.0 mm
Depth: 3.66″ 92.9 mm
REPLACEMENT PARTS
Description Part Number
Volume Control Kit K8435663B
Coil, 120VAC (350 Horn only) KFC1516C
SPECIFICATIONS Operating Temperature: -65°F to 150°F -54°C to 66°C Net Weight: 2.7 lbs. 1.2 kg Shipping Weight: 2.8 lbs. 1.2 kg Height: 4.53″ 115.0 mm Width: 4.53″ 115.0 mm Depth: 3.66″ 92.9 mm REPLACEMENT PARTS Description Part Number Volume Control Kit K8435663B Coil, 120VAC (350 Horn only) KFC1516C
