BALIZA ESTROBOSCOPICA ANTIEXPLOSIVA 12-24VDC 3/4″NPT C/REJ. ROJO NEMA 4X UL 151XST-012-024R FEDERAL SIGNAL
Hazardous Location Warning Light Model 151XST 5yr W A R R A N T Y Federal Signal’s Model 151XST hazardous location strobe light provides 80 high-intensity flashes per minute. This warning light is available in 12-24VDC, 120VAC and 240VAC, 50/60Hz. The Model 151XST strobe light is UL Listed and CSA Certified for Class I, Division 2, Groups A, B, C and D; Class II, Division 1, Groups E, F and G; and Class III. The 151XST meets Type 4X water-tight, dust-tight, and corrosionresistant requirements and is constructed to IP66. This hazardous location warning light has an aluminum base, coated for corrosionresistance, that can be ordered for mounting on a 3/4-inch NPT pipe or a surface. The Dome Guard (included) fits over the glass dome to protect it against accidental collision with moving equipment, such as forklifts. The 151XST produces 165 effective candela (ECP) and 520,000 peak candela. It is available in five dome colors including Amber, Blue, Clear, Green, Magenta and Red. Federal Signal’s rugged 151XST strobe warning light is specifically designed for hazardous locations or corrosive environments where a very bright visual signal is required. This warning light can be used for plant evacuation or other communication needs.
RUGGED DESIGN FOR USE IN
HAZARDOUS LOCATIONS
• Available in 12-24VDC, 120VAC and
240VAC
• Six dome colors
• 10,000-hour high-intensity strobe
• Available in 3/4-inch NPT pipe mount
or surface mount
• Dome guard included
• Indoor/outdoor use
• Type 4X, IP66 enclosure
• Marine rated
• UL and cUL
Listed
Operating Flash Rate/ Candela Model Voltage Current Minute Peak1 ECP2 Mount 151XST-_*012-024-** 12-24VDC 1.3-0.60 amps 80 520,000 165 3 /4″ NPT Pipe 151XST-_*120-** 120VAC 50/60Hz 0.35 amps 80 520,000 165 3 /4″ NPT Pipe 151XST-_*240-** 240VAC 50/60Hz 0.18 amps 80 520,000 165 3 /4″ NPT Pipe * Include (S) for Surface Mount Option (Example part number: 151XST-S120R for surface mount option, 151XST-120R for pipe mount) ** Indicates color: (A) Amber, (B) Blue, (C) Clear, (G) Green, (M) Magenta or (R) Red 1 Peak candela is the maximum light intensity generated by a flashing light during its light pulse 2 ECP (Effective Candela) is the intensity that would appear to an observer if the light were burning steadily
