SAB200
Campana Industrial C/Baliza Serie SAB Decibeles: 95 – QLIGHT
• Electric solenoid bell system provides excellent durability to vibration and shock for vessels and large facilities • Special material for bell housing provides clear and crisp alarm sound • Excellent vibration and shock resistant structure for superior durability • Easy wiring and maintenance with terminal box attached • Lamp attached provides visual signals • Bell and lamp operation is synchronized. Each function can also operate separately • Sound volume : Max 95dB at 1m • Standard color : Housing-beige, Bell/ Lamp-Red • Materials : Bell-Steel, Housing-ABS • Ambient operating temperature : -25°C to +50°C • Protection rating : IP56 • Cable entry : PG19 Model number Frequency Volume Bell diameter Voltage Current Certificates Weight Bell/ Lamp color SAB130 400-600Hz 95dB 130mm DC24V 1.377A – 1.88kg AC110V 0.166A ● R-Red SAB200 200mm 2.00kg
SAB130 -Bell housing Ø130mm SAB200 -Bell housing Ø200mm SAB130/ SAB200 Max 95dB 56 5025 95 • Two way cable entries with PG19 Customization Ordering Specification (Units : mm) S
• Electric solenoid bell system provides excellent durability to vibration and shock for vessels and large facilities • Special material for bell housing provides clear and crisp alarm sound • Excellent vibration and shock resistant structure for superior durability • Easy wiring and maintenance with terminal box attached • Lamp attached provides visual signals • Bell and lamp operation is synchronized. Each function can also operate separately • Sound volume : Max 95dB at 1m • Standard color : Housing-beige, Bell/ Lamp-Red • Materials : Bell-Steel, Housing-ABS • Ambient operating temperature : -25°C to +50°C • Protection rating : IP56 • Cable entry : PG19 Model number Frequency Volume Bell diameter Voltage Current Certificates Weight Bell/ Lamp color SAB130 400-600Hz 95dB 130mm DC24V 1.377A – 1.88kg AC110V 0.166A ● R-Red SAB200 200mm 2.00kg AC220V 0.116A Technical Diagram Specifications SAB130 -Bell housing Ø130mm SAB200 -Bell housing Ø200mm SAB130/ SAB200 Max 95dB 56 5025 95 • Two way cable entries with PG19 Customization Ordering Specification (Units : mm) S
