SIRENA C/BALIZA LED FIJA/INTERMITENTE 110/220VAC 105dB IP65 AZUL QAD125BZ-110/220-B QLIGHT
LED Waring Lights with High Volume Built-in Buzzer QAD100/ 125BZ QAD100BZ – 110/220 – R [Model number] [Voltage] [Color] | | | • QAD100BZ • QAD125BZ • 12-DC12V • 24-DC24V • 110/220 – AC110V-220V R-Red A-Amber G-Green B-Blue Model number Voltage Current Sound pattern and volume Certificates Weight Color QAD100BZ DC12V 0.460A Buzzer Volume : Max. 105dB 0.98Kg R-Red A-Amber G-Green B-Blue DC24V 0.290A AC110V220V Max. 0.145A 1.01Kg QAD125BZ DC12V 0.460A Buzzer Volume : Max. 105dB 1.22Kg DC24V 0.290A AC110V220V Max. 0.145A 1.27Kg Thank you for purchasing Qlight’s products. Please read this user manual carefully prior to installation and operation to ensure safe and correct use.
Failure to follow the instructions below may cause a loss of life or serious physical injury. 1. Please remove any objects that can interrupt ventilation around the product. 2. Please turn off the power of the product immediately if it fails to operate properly. 3. Carefully wire the product according to each product’s specification. 4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product. 5. Do not apply excessive force/impact to the product. 6. Failure to follow any of the instructions above may cause malfunction or damage to the product, fire, and electric shock. Precautions for Correct Use Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product that would void the warranty. 1. During wiring or maintenance, please completely turn off the power of the product. (Failure to follow this may lead to an electric shock.) 2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection ratings indicated for each product. (Failure to follow these instructions may cause a fire to the product, electric shock, physical injury, malfunction or damage to the product.) 3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to follow these instructions may lead to fire, electric shock, or product damage.) 4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to fire, electric shock, or product damage.) 5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to follow this may cause damage to property, fire, electric shock and loss of life.)
