SIRENA MOTORIZADA SM30 12VDC 110dB IP44 SM30-12 QLIGHT
SM30-12
Motor Siren SM30/ SM40/ SM200/ SM400 SM40 – 110 [Model number] [Voltage] | | • SM30 • SM40 • 12 – DC12V • 24 – DC24V • 110 – AC110V • 220 – AC220V • SM200 • SM400 • 24 – DC24V • 110 – AC110V • 220 – AC220V • Ambient operating temperature : -25°C to +50°C Model number Volume Voltage Current Certificate Weight Rated time SM30 110dB DC12V 5.100A 0.22kg 10 min. DC24V 2.500A AC110V 1.220A 0.42kg AC220V 0.610A SM40 116dB DC12V 6.778A 0.53kg 10 min. DC24V 3.666A AC110V 1.000A 0.68kg AC220V 0.722A SM200 120dB DC24V 7.820A 2.19kg AC110V 2.105A 10 min. 2.55kg AC220V 1.005A SM400 123dB DC24V 12.000A 3.19kg AC110V 6.300A 3 min. 3.75kg AC220V 3.800A ※ CE compliant : DC24V(SM200) Please scan the QR code for more detailed product information. www.qlight.com Ordering Specifications Product Specifications Precautions for Safety Failure to follow the instructions below may cause a loss of life or serious physical injury. 1. Please remove any objects that can interrupt ventilation around the product. 2. Please turn off the power of the product immediately if it fails to operate properly. 3. Carefully wire the product according to each product’s specification. 4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product. 5. Do not apply excessive force/impact to the product. 6. Failure to follow any of the instructions above may cause malfunction or damage to the product, fire, and electric shock. Precautions for Correct Use Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the product that would void the warranty. 1. During wiring or maintenance, please completely turn off the power of the product. (Failure to follow this may lead to an electric shock.) 2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection ratings indicated for each product. (Failure to follow these instructions may cause a fire to the product, electric shock, physical injury, malfunction or damage to the product.) 3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to follow these instructions may lead to fire, electric shock, or product damage.) 4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to fire, electric shock, or product damage.) 5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to follow this may cause damage to property, fire, electric shock and loss of life.) SM30-12
