CIRCULINA GIRATORIA SERIE S100UA 12V ROJO IP44 S100UA-12-R QLIGHT
Model number Voltage Current Bulb Certificates Weight Color Spec Standard Parts no S100U S100UA DC12V 0.966A 12V10W T16x35 15S 9 0.36kg ● R-Red ● A-Amber ● G-Green ● B-Blue DC24V 0.566A 24V10W T16x35 15S 10 0.36kg AC110V 0.130A 12V10W T16x35 15S 9 0.59kg AC220V 0.065A 12V10W T16x35 15S 9 0.59kg S100U S100UA • Protection rating : IP44 • External power line standard : UL1015 AWG18(0.75sq)×2C 400mm • DC type : Black output line is negative(-) • 2 buzzer sound types : Both prolonged(beep, beep) and staccato(beep, beep, beep) buzzer output available Ordering Specification Wiring Instructions Technical Diagram S100U/ S100UA Bulb Revolving Signal Lights Customization S100UR Wall Mount Bracket SWP125 Wall Mount Bracket SWM125 44 20 50 90 (Units : mm) Enhanced diffusion through a special 12 sided diffusive lens S100U set on 1st floor security gate of public office for disabled persons. S100U 152 93 46 12 Ø101 Ø10 CABLE ENTRY PCD 60 360˚/3-M4 BOLT Ø10 CABLE ENTRY PCD 60 360˚/3-M4 BOLT S100UA 155 12 96 46 Ø101 S100U – BZ – 220 – R [Model number] [Buzzer option] [Voltage] [Color] | | | | • S100U • S100UA • None – No buzzer • BZ – Built-in buzzer • 12-DC12V • 24-DC24V • 110-AC110V • 220-AC220V ● R-Red ● A-Amber ● G-Green ● B-Blue S
