MFL125
Circulina LED IP65 El producto tiene múltiples funciones de LED fijo / intermitente, estroboscópico y giro simulado.
Opciones de operación con interruptores dentro del producto o conexión externa.
Resistente a choques y vibraciones, se reduce el mantenimiento con una bombilla LED de bajo consumo de energía eficiente.
Zumbador incorporado disponible (volumen: máx. 80dB a 1 m)
Tipos de parpadeo de tipo intermitente (LF): 60-80 flashes / min
Tasas de parpadeo del tipo estroboscópico (LS): 70-80 flashes / min
Tasas de parpadeo de tipo giratorio simulado (LR): 120-140 flashes / min
Materiales: Lente-PC, carcasa-ABS
Circulina LED IP65
Temperatura ambiente de funcionamiento: -30 ° C a + 50 ° C
Grado de protección: IP65
Certificados: Denuncia CE
Queja con la directiva RoHS
Model number Voltage Current Certificates Weight Color MFL100 DC12V-24V Max 0.255A DC only 0.30kg ● R-Red ● A-Amber ● G-Green ● B-Blue AC110V-220V Max 0.067A 0.52kg Model number Voltage Current Certificates Weight Color MFL125 DC12V-24V Max 0.255A DC only 0.52kg ● R-Red ● A-Amber ● G-Green ● B-Blue AC110V-220V Max 0.067A 0.92kg MFL125 MFL100 – BZ – 110/220 – R [Model number] [Buzzer option] [Voltage] [Color] | | | | • MFL60 • MFL80 • MFL100 • MFL125 • None – No buzzer • BZ – Built-in buzzer • 12/24 -DC12V-24V • 110/220 -AC110V-220V ● R-Red ● A-Amber ● G-Green ● B-Blue MFLseries LED Signal Light with Multiple Light Functions ※ DC type model has a free-voltage range of 10V-30V. ※ AC type model has a free-voltage range of 100V-240V
• External power line standard : UL1015 AWG18(0.75sq)×2C 400mm • Product can be wired regardless of polarity Ordering Specification Wiring Instructions MFL100 Multi-functional model with selectable steady/ flashing strobe, and simulated revolving flashing mode Technical Diagram MFL100 Ø100mm Multiple Light Function LED Signal Light MFL125 Ø125mm Multiple Light Function LED Signal Light 65 5030 80 – MFL60 – MFL80 – MFL100/ MFL125 (Units : mm) Model number Voltage Current Certificates Weight Color MFL100 DC12V-24V Max 0.255A DC only 0.30kg ● R-Red ● A-Amber ● G-Green ● B-Blue AC110V-220V Max 0.067A 0.52kg Model number Voltage Current Certificates Weight Color MFL125 DC12V-24V Max 0.255A DC only 0.52kg ● R-Red ● A-Amber ● G-Green ● B-Blue AC110V-220V Max 0.067A 0.92kg MFL125 MFL100 – BZ – 110/220 – R [Model number] [Buzzer option] [Voltage] [Color] | | | | • MFL60 • MFL80 • MFL100 • MFL125 • None – No buzzer • BZ – Built-in buzzer • 12/24 -DC12V-24V • 110/220 -AC110V-220V ● R-Red ● A-Amber ● G-Green ● B-Blue
