CIRCULINA LED SERIE EQ100 FLASH/ROTATIVA 220VAC ROJO IP44 EQ100-BZ-220-R QLIGHT
Materials Lens-PC, Housing-ABS Ambient operating temperature -30℃ to +50℃ Volume Max.90dB at 1m(Built-in buzzer type) Protection rating IP44 Simulated revolving type(LR) flashing rates 120-140RPM Strobe type(LS) flashing rates 70-80/min Compliant with RoHS directive
– Standard-sized signal lights of Ø100mm with attractive appearance – Direct mount type with the three bolts/screws located on the bottom of the product – Shock and vibration-resistant, maintenance reduced with long-lasting energy efficient LED ligh – Features high visibility with special diffusive lens and direct LED light distribution system
EQ100 EQ100-BZ DC24V Max.0.085A – 0.30kg R-Red G-Green A-Amber B-Blue AC220V Max.0.140A ※ LR(Simulated revolving)/ LF(Flashing) type is available. ㆍExternal Power line – UL1015 AWG18(0.75sq) x 2C 400mm ㆍDC Type: Black output line is negative( – ) Wiring Instructions EQ100 – BZ – 24 – R [Model number] ㅣ EQ100 EQ100-BZ [Buzzer option] ㅣ None – No buzzer BZ – Built-in buzzer [Voltage] ㅣ 24-DC24V 220-AC220V [Color] ㅣ R-Red G-Green A-Amber B-Blue ·EQ100 EQ100 Ø100mm Steady/Flashing, strobe beacon light – Standard-sized signal lights of Ø100mm with attractive appearance – Direct mount type with the three bolts/screws located on the bottom of the product – Shock and vibration-resistant, maintenance reduced with long-lasting energy efficient LED ligh – Features high visibility with special diffusive lens and direct LED light distribution system EQ100 Materials Lens-PC, Housing-ABS Ambient operating temperature -30℃ to +50℃ Volume Max.90dB at 1m(Built-in buzzer type) Protection rating IP44 Simulated revolving type(LR) flashing rates 120-140RPM Strobe type(LS) flashing rates 70-80/min Compliant with RoHS directive PRODUCT SPECIFICATION M
Manual switch to select operation ㆍPlease refer to the chart below to use light function selection switch located inside the product. Light function ON LED Strobe OFF LED Simulated revolving flashing ON=1 OFF=0 Operation ㆍLED Simulated Revolving LEDs flash steadily around the cylindrical LED filaments which makes a simulated revolving effect ㆍLED Strobe Short LED Steady/ Flashing cycle. Creates a xenon flashing effect by providing maximum electric current
