QNE SERIES
Circulina Antiexplosiva LED compacta, multifuncional y a prueba de explosiones diseñada para su uso en entornos con gases explosivos con clasificación Ex d Ⅱ C, Presenta una excelente resistencia a golpes y vibraciones, se reduce significativamente el mantenimiento con una fuente de luz LED duradera.
Circulina Antiexplosiva LED
Una variedad de selecciones de sonido entre sonidos de advertencia, sonidos de alarma, melodías y mensajes de voz para adaptarse a sus sofisticadas necesidades de aplicación
Características de durabilidad superior con carcasa de aluminio
Estructura completamente cerrada con índice de protección IP66
Color estándar de la carcasa: Rojo, MUNSELL No. 7.5BG 7/2
Entrada de cable: 1/2 ″ NPT
Velocidad de parpadeo (tipo LF): 60-80 / min; Estroboscópica (tipo LR): 70 ~ 80 / min; Rotación simulada (tipo LR): 120 ~ 140 RPM
Materiales: Lente-PC, lente interior, vidrio templado, soporte-SUS304, carcasa-Al
Certificados: ATEX, IECEx
• LED Steady/ Flashing Repeat operation of LED light on/off Instruction for Light Function Switch • LED Strobe Short LED steady/flashing. Creates a xenon flashing effect by providing maximum electric current • LED Simulated Revolving Flashing LED flashes steadily around the cylindrical LED filaments which makes a simulated revolving effect ON=1 / OFF=0 Can select 4 different kinds of light functions with switch configuration No. 1 2 Operation 0 0 0 LED Steady 1 0 1 LED Flashing 2 1 0 LED Strobe 3 1 1 LED Simulated revolving flashing ON OFF 1 2 Flame proof LED signal light that features steady/flashing, strobe, and simulated revolving light functions in one unit Model number Voltage Current Certificates Weight Color QNE DC12V-24V Max. 0.558A 2.05kg ● R-Red ● A-Amber ● G-Green AC110V-220V Max. 0.136A ● B-Blue QNE series Ø92mm Explosion Proof LED Signal/ Warning Light Spec
• Explosion proof, multifunctional, and compact LED signal light designed for use in explosive gas environments with Ex d ⅡC rating • Features excellent shock and vibration resistance, maintenance significantly reduced with long-lasting LED light source • Features superior durability with aluminum housing(QNE) • STS housing provides superior durability and corrosion resistance(QNE-SUS) • Features excellent corrosion resistance with brass housing(QNE-BS) • Fully enclosed structure with protection rating of IP66 • Housing standard color : Red, MUNSELL No. 7.5BG 7/2 • Cable entry : 1/2″ NPT • Flashing rate(LF type) : 60-80 flashes/min. • Strobe rate(LS type) : 70-80 flashes/min. • Simulated revolving rate(LR type) : 120-140RPM • Materials : Lens-Tempered glass, Inner lens-PC, Bracket-STS304, Protection cage-STS316, Housing-Al(QNE), STS(QNE-SUS), Brass(QNE-BS) • Certificates : ATEX, IECEx, KCs • Protection rating : ATEX – Ⅱ2G Ex dⅡC T5/ T6, IP66 IECEx, KCs – Ex dⅡC T5/ T6, IP66 • Ambient operating temperature : -40°C ≤ Tamb ≤ +60°C -40°C ≤ Tamb ≤ +50°C QNE Explosion Proof Signal/ Warning Light • LED Steady/ Flashing Repeat operation of LED light on/off Instruction for Light Function Switch • LED Strobe Short LED steady/flashing. Creates a xenon flashing effect by providing maximum electric current • LED Simulated Revolving Flashing LED flashes steadily around the cylindrical LED filaments which makes a simulated revolving effect ON=1 / OFF=0 Can select 4 different kinds of light functions with switch configuration No. 1 2 Operation 0 0 0 LED Steady 1 0 1 LED Flashing 2 1 0 LED Strobe 3 1 1 LED Simulated revolving flashing ON OFF 1 2 Flame proof LED signal light that features steady/flashing, strobe, and simulated revolving light functions in one unit Model number Voltage Current Certificates Weight Color QNE DC12V-24V Max. 0.558A 2.05kg ● R-Red ● A-Amber ● G-Green AC110V-220V Max. 0.136A ● B-Blue QNE series Ø92mm Explosion Proof LED Signal/ Warning Light Specifications (QNE/ QNE-SUS/ QNE-BS) • Features superior durability with aluminum housing
