QLEX-SLM-650-ATEX
http://mcsuministros.com/wp-content/uploads/2024/04/QLEX-SLM-QLIGHT.pdf
LUMINARIA ANTIEXPLOSIVA 23W 520LUX 220VAC IP66 ATEX QLEX-SLM-650-ATEX QLIGHT
QLEX-SLM series Explosion Proof LED Work Light Optics Specifications Model QLEX-SLM-250 QLEX-SLM-650 Lens color Translucent Light color Cool daylight Color temperature 6,000~7,000K Efficacy (lm/W) DC 240Lux 530Lux Specifications Model number QLEX-SLM-250 QLEX-SLM-650 Rated voltage DC24V AC220V DC24V AC220V Range for operation voltage DC21.6V-26.4V AC198V-242V DC21.6V-26.4V AC198V-242V Power consumption 8.6W 9.0W 20W 23W Insulation resistance Min. 100MΩ(1,500V AC / 500V DC mega ohm meter) Withstanding voltage DC : 500VAC, 60Hz, 1minute / AC : 1,500VAC, 60Hz, 1minute Protection rating IP66/ 67 Materials Side cover : Al, Lens : PC, Bracket : Al Certificates – Weight(approx.) 0.50Kg 0.93Kg 66 67 40 60 QLEX-SLM series Explosion Proof LED Work Light 모델선정 QLEX-SLM – 250 – 24 [Model number] [Length] [Voltage] | | | • QLEX-SLM • 250-250mm • 650-650mm • 24-DC24V • 220-AC220V Specifications Ø49.2 (750) (900) A 5 25 45 64.5 54 90 104 C B ±2 ±2 Ø40 Ø45 • Explosion proof LED work light designed for use in explosive gas environments with Ex d IIC rating • Enhanced durability with aluminum housing and polycarbonate lens tube • Semi-permanent service life with long-lasting LED light source • Features special structure that allows to adjust light angle by turning the light tube • Materials : Side cover-Al, Lens-PC, Bracket-Al • Certificates : CE, KCs, NEPSI, S-mark • Protection rating : KCs – Ex d ⅡC T6 NEPSI – Ex db ⅡC T6 Gb (QLEX-SLM
• Explosion proof LED work light designed for use in explosive gas environments with Ex d IIC rating • Enhanced durability with aluminum housing and polycarbonate lens tube • Semi-permanent service life with long-lasting LED light source • Features special structure that allows to adjust light angle by turning the light tube • Materials : Side cover-Al, Lens-PC, Bracket-Al • Certificates : CE, KCs, NEPSI, S-mark • Protection rating : KCs – Ex d ⅡC T6 NEPSI – Ex db ⅡC T6 Gb (QLEX-SLM-250) • Ambient operating temperature : -40°C ≤ Tamb ≤+60°C
