S80AU
Circulina Garaje Giratoria S80 Series IP44 QLIGHT
Luz de advertencia giratoria de bulbo de Ø80mm máx. 90dB.
Placa de terminales Tipo incorporado de fácil cableado, que emplea un sistema de transmisión de potencia especial
Circulina Garaje Giratoria S80 Series IP44 QLIGHT
Entonces el soporte de pared equipado permite un fácil montaje. No se requieren soportes de montaje adicionales
El bloque de terminales diseñado dentro del soporte de montaje lateral, por lo tanto, permite un fácil cableado
Zumbador incorporado disponible (volumen: máx. 90dB a 1 m)
Velocidad de rotación: 120-140 rpm
Materiales: Lens-AS, Carcasa ABS, Reflector resistente al calor ABS
Temperatura ambiente de funcionamiento: -20 ° C a + 50 ° C
Grado de protección: IP44
Equipped wall mount allows for easy assembly. Additional mounting brackets not required • Terminal block designed inside the side mount bracket enables easy wiring • Built-in buzzer available (Volume : Max 90dB at 1m) • Revolving speed : 120-140RPM • Materials : Lens-AS, Housing-ABS, Reflector-Heat resistant ABS • Ambient operating temperature : -20°C to +50°C • Protection rating : IP44 S80AU Bulb Revolving Warning Lights Model number Voltage Current Bulb Certificates Weight Color Spec Standard Parts no S80AR S80AU DC12V 0.484A 12V5W T16x35 15S 5 – 0.31kg ● R-Red ● A-Amber ● G-Green ● B-Blue DC24V 0.310A 24V5W T16x35 15S 6 0.31kg AC110V 0.080A 12V5W T16x35 15S 5 0.50kg AC220V 0.040A 12V5W T16x35 15S 5 0.50kg Technical Diagram • Attach the power supply wire to the terminal block • DC Type : Black output line is negative(-) Wiring Instructions Mounting Instructions Ordering Specification Secure the base plate to the mounting surface, and the power line to the terminal block Mount the warning light by inserting the ring(hook) into the upper part of the base plate Screw in the bolt at the base of the mounting bracket to complete assembly 44 5020 90 Specifications 1 2 3 1 2 3 (Units : mm) S80A series enable easy wiring S80A series enables easy wiring with its terminal block attached to the fixed base plate. With this system the contacts in the housing sends power directly to the terminal block. S80AR – BZ – 220 – R [Model number] [Buzzer option] [Voltage] [Color] | | | | • S80AR • S80AU • None – No buzzer • BZ – Built-in buzzer • 12-DC12V • 24-DC24V • 110-AC110V • 220-AC220V ● R-Red ● A-Amber ● G-Green ● B-Blue S80series Ø
