Procedencia: Inglaterra, Stock: Consultar
PNC-0063
http://mcsuministros.com/wp-content/uploads/2024/03/NEXUS-AUDIBLE-VISUAL-110-AC-2.pdf
SIRENA C/BALIZA NEXUS 24-48VAC AMBAR PNC-0063 KLAXON
Nexus 110 Sounder Beacon (AC) The Nexus 110 is a high output, sounder beacon designed for industrial applications. Connections are made to the base during the initial wiring phase which results in faster and more reliable installation. In addition, the head is fixed by quarter turn fasteners enabling faster installation and accurate seal compression for weatherproofing. The combination of powerful sounder and high output beacon ensures a very effective audio-visual signal. Features ■ High sound output: 116dB (max); 110dB typical ■ Low voltage AC variant ■ 5J xenon and LED beacon options ■ Three alarm stages ■ Quarter turn fasteners for ease of installation ■ First-fix, wire to base technology ■ IP66 rated ■ Volume control for greater flexibility – 20dB ■ 64 tones ■ Separate connections for sounder & beacon
Part No. Lens Colour Beacon Type Audibility at 1m Dimensions: Tones Voltage Sounder Current Beacon Current PNC-0062 Red lens LED beacon 116dB (A) 64 24-48V AC 30-100mA – PNC-0063 Amber lens LED beacon 116dB (A) 64 24-48V AC 30-100mA – PNC-0016 Red lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0018 Amber lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0072 Clear lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0051 Blue lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0049 Green lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA
Part No. Lens Colour Beacon Type Audibility at 1m Dimensions: Tones Voltage Sounder Current Beacon Current PNC-0062 Red lens LED beacon 116dB (A) 64 24-48V AC 30-100mA – PNC-0063 Amber lens LED beacon 116dB (A) 64 24-48V AC 30-100mA – PNC-0016 Red lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0018 Amber lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0072 Clear lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0051 Blue lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0049 Green lens Xenon 5J beacon 116dB (A) 64 110/230V AC 40mA (max) 70mA
