SIRENA C/BALIZA LED SONOS 32 TONOS AMBAR PSC-0025 KLAXON

PSC-0025

http://mcsuministros.com/wp-content/uploads/2024/03/SONOS-AUDIBLE-VISUAL-DC.pdf

SIRENA C/BALIZA LED SONOS 32 TONOS 24/48VDC 80-106dB IP65 AMBAR PSC-0025 KLAXON

Sonos Sounder Beacon (DC) A general purpose electronic sounder for fire, security and industrial applications; the Sonos Sounder Beacon is certified to EN54. With the TimeSaver base, connections are made to the base during the initial wiring phase which results in faster and more reliable installation. The sounder head ‘twists and clicks’ into the base on commissioning, avoiding the wiring and connection problems associated with traditional sounders. With a choice of 32 tones including all the major international standards, the Sonos Sounder Beacon has universal acceptance. Features ■ Low current LED beacon ■ Simple ‘First Fix’ installation ■ Weatherproof to IP65 (deep base units) ■ Choice of lens colours ■ Sounder and beacon can be controlled separately ■ Tone and volume can be preset or adjusted off-base – 20dB ■ Separate connections for sounder & beacon Lens Colour Options

Part No. Base Colours Audibility at 1m Tones Voltage Sounder Current Beacon Current PSC-0002 Red shallow base Red lens Up to 106dB (A) 32 17-60V DC 4-45mA 5mA PSC-0025 Red shallow base Amber lens Up to 106dB (A) 32 17-60V DC 4-45mA 5mA PSC-0013 Red deep base Red lens Up to 106dB (A) 32 17-60V DC 4-45mA 5mA PSC-0027 Red deep base Amber lens Up to 106dB (A) 32 17-60V DC 4-45mA 5mA PSC-0035 White shallow base Red lens Up to 106dB (A) 32 17-60V DC 4-45mA 5mA PSC-0040 White shallow base Amber lens Up to 106dB (A) 32 17-60V DC 4-45mA 5mA PSC-0029 White deep base Red lens Up to 106dB (A) 32 17-60V DC 4-45mA 5mA PSC-0034 White deep base Amber lens Up to 106dB (A) 32 17-60V DC 4-45mA 5mA Specifications Other colours/combinations are available on request IP Rating: IP65 (deep base) IP21 (shallow base) Operating Temp: -25ºC to +70ºC Construction: Flame Retardant Polycarbonate Cable Entries: Deep Base: 2 x 20mm cable glands Weight: 0.22kg (shallow base) 0.25kg (deep base) Compliance: EN54 3 Type A (shallow base) EN54 3 Type B (deep base) Applications – Fire; security; industrial alarm Deep Base Shallow Base 6<67(0(‘( 6(&85,7(,1&(1’,( S
