SIRENA C/BALIZA ESTROBOSCOPICA VERDE PNC-0042 KLAXON

PNC-0042

http://mcsuministros.com/wp-content/uploads/2024/03/NEXUS-AUDIBLE-VISUAL-105-AC.pdf

SIRENA C/BALIZA ESTROBOSCOPICA NEXUS 64TONOS 110/230VAC 113dB IP66 VERDE PNC-0042 KLAXON

Nexus 105 Sounder Beacon (AC) The Nexus 105 is a high output sounder-beacon designed for industrial applications. Connections are made to the base during the initial wiring phase which results in faster and more reliable installation. In addition, the head is fixed by quarter turn fasteners enabling faster installation and accurate seal compression for weatherproofing. The combination of powerful sounder and high output xenon beacon ensures a very effective audio-visual signal. 110dB and 120dB units, as well as DC variants, are also available. Features ■ High sound output: 113dB (max); 105dB typical ■ 5J xenon beacon ■ Quarter turn fasteners for ease of installation ■ First-fix, wire to base technology ■ IP66 rated ■ Volume control for greater flexibility – 20dB ■ 64 tones ■ Separate connections for sounder & beacon

Part No. Lens Colour Beacon Type Audibility at 1m Tones Voltage Sounder Current Beacon Current PNC-0005 Red lens 5J xenon beacon Up to 113dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0007 Amber lens 5J xenon beacon Up to 113dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0019 Clear lens 5J xenon beacon Up to 113dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0044 Blue lens 5J xenon beacon Up to 113dB (A) 64 110/230V AC 40mA (max) 70mA PNC-0042 Green lens 5J xenon beacon Up to 113dB (A) 64 110/230V AC 40mA (max) 70mA

CATEGORIA DE PRODUCTOS/Sirenas y Luces de Señalización/Sirenas con Circulina

SIRENA C/BALIZA ESTROBOSCOPICA VERDE PNC-0042 KLAXON
